Specifications
XLK6036C
XLK6036CL
XLK6030
Spindle hole taper
7:24 ISO50
7:24 ISO40
Distance between spindle and table surface
10-460mm
75-475mm
Distance from spindle axis to arm
175mm
155mm
Spindle speed range
12 steps 60-1800r/min
12 steps 35-150r/min
Arm travel
500mm
/
Table size
1325x360mm
1600x360mm
1370x300mm
Table travel X/Y/Z axis
1100/320/450mm
1300/320/450mm
820/300/400mm
Table rapid feed speed
4000/4000/3000mm/min
T-slot (No./width/pitch)
3pcs/18/70mm
3pcs/14/80mm
Main motor power
5.5kW
3kW
Torque of X/Y/Z axis AC servo motor
10/10/18N.m
10/10/15N.m
Overall size (LxWxH)
2400x2000x1870mm
2800x2000x1870mm
1850x1760x1800mm
Net weight
2465kg
2510kg
1850kg
Standard Accessories
Optional Accessories
SIEMENS808D
The 4th axis CNC rotary table
CNC dividing head
CNC system FANUC, Mitsubishi, GSK980MDC
