Graphite coating on face grinder increases sliding capacity of sanding belt.
High belt speed ensures excellent grinding performance.
Wide range of applications such as contour, surface and cylindrical grinding.
Quick adjustment from vertical to horizontal grinding.
Solid and torsion-free machine housing guarantees smooth run.
Efficient deburring of edges, buffing of welding seams.
Sanding disc with Velcro fastener, ideal for multiple change of grit.
Model BDS 75-2 comes with 2 speed settings and adjustable workpiece support.
Sanding belt is easy to change, manual adjustment of belt tension.
|
Specifications |
BDS75 |
BDS75-2 |
|
Sanding belt |
75x1180mm |
75x1180mm |
|
Belt speed |
11m/sec. |
11/22m/sec. |
|
Belt sanding table |
280x80mm |
280x80mm |
|
Belt sanding table tiltable |
0°-90° |
0°-90° |
|
Sanding disc dia. |
150mm |
150mm |
|
Sanding disc table |
150x130mm |
150x130mm |
|
Sanding disc table tiltable |
0°-45° |
0°-45° |
|
Dust extraction outlet |
50mm |
50mm |
|
Motor power output S1 100% |
1.1kW |
1.5/1.8kW |
|
Motor power input S6 40% |
1.5kW |
2.1/2.5kW |
|
Voltage |
400V |
400V |
|
Packing size |
730x585x540mm |
730x585x540mm |
|
Weight approx |
65kg |
69kg |
