9” round cutting capacity.
Gear drive, powerful cutting saw with 3 cutting speed.
Hydraulic cylinder control the saw bow descent.
Swivel vice to achieve miter cutting.
Standard cooling system.
Specifications |
BS-912G |
|
Capacity |
Circular @90° |
229mm (9") |
Rectangular @90 ° |
178x305mm (7"x12") |
|
Circular @45° |
150mm (6") |
|
Rectangular @45 ° |
127x150mm (5"x6") |
|
Blade speed |
60Hz |
38,78,115m/min |
50Hz |
31,65,95m/min |
|
Blade size |
27x0.9x2655mm |
|
Motor power |
1.1kW 1.5HP (3Ph or 1Ph) |
|
Drive |
Gear |
|
Packing size |
158x62x115cm |
|
N.W./G.W. |
220/250kg |
Standard Accessories |
Coolant system |
Saw blade |
Stop rod |
