Max. cutting 9" round at 90°.
Belt drive, variable cutting speed, cut almost anything can put on it.
Hydraulic descent pressure controlled by a panel located on top of the bow.
Fully welded structure minimize vibrations to deliver clean, accurate cuts.
Standard coolant system to wash the chips on the blade, help blade life last longer.
Stop rod help you cutting reputably in the same size.
Fast clamp vice easy to hold the material.
Swivel saw bow easily to get angle cutting, quick lock for saw frame swivel.
Specifications |
BS-916VR
|
|
Capacity |
Circular @90° |
229mm (9")
|
Rectangular @90 ° |
127x405mm (5"x16")
|
|
Circular @45° |
150mm (6")
|
|
Rectangular @45 ° |
150x190mm (6"x7.5")
|
|
Blade speed |
60Hz |
22-122m/min
|
50Hz |
18-102m/min
|
|
Blade size |
27x0.9x3215mm
|
|
Motor power |
1.5kW 2HP (3Ph)
|
|
Drive |
V-belt
|
|
Packing size |
188x78x136cm
|
|
N.W./G.W. |
320/380kg
|
Standard Accessories |
Coolant system |
Saw blade |
Stop rod |
