Ball bearing guide and precision vise for accurate straight or angle cut.
Four wheels for easy machine moving.
Coolant pump for blade cooling.
Automatic cut-off switch.
|
Specifications |
G4023 |
|
Motor |
1100W (230V) |
|
1100/590W (380V) |
|
|
Blade size |
2450x27x0.9mm |
|
Blade speed |
72 (230V), 87 (110V), 72/36 (380V) |
|
The bow swivel degree |
0°-60° |
|
Cutting capacity at 90° |
●220mm |
|
■150x150mm |
|
|
▅260x150mm |
|
|
Cutting capacity at 45° |
●150mm |
|
■145x145mm |
|
|
▅150x145mm |
|
|
Cutting capacity at 60° |
●90mm |
|
■85x85mm |
|
|
▅100x85mm |
|
|
Table height |
1045mm |
|
N.W./G.W. |
218/264kg |
|
Packing size |
1450x570x1040mm (body) |
|
Unit/20' container |
28pcs |
