Headstock adopts mechanical or electromagnetic brake.
The mechanism of speed change works in the way of centralized driven.
The appearance is novel and desirable and its overall layout is reasonable.
The machine is applied to process small parts.
The spindle system has good rigidity and high precision.
|
Specifications |
KE1-60 |
KE2-60/80/100/150 |
KL36B-60/100 |
|
Swing over bed |
330mm |
360mm |
360mm |
|
Distance between centers |
600mm |
600/800/1000/1500mm |
600/1000mm |
|
Spindle bore |
38mm |
||
|
Taper of spindle bore |
MT5 |
||
|
Range of spindle speed |
6 steps 80-930r/min |
9 steps 60-2000r/min |
|
|
Quill taper of tailstock |
MT3 |
||
|
Quill taper of drilling spindle |
MT4 |
/ |
|
|
Range of drilling spindle speed |
250-740r/min |
/ |
|
|
Drilling spindle travel |
100mm |
/ |
|
|
Drilling table vertical travel |
380mm |
/ |
|
|
Packing size |
1940x675x1585mm |
1940/2140/2340/2840x675x1600mm |
1400/1800x675x1200mm |
|
N.W. |
888kg |
896/925/948/1006kg |
630/692kg |
