Specifications
M618A
M820
M1022
Table Size (LxW)
460x180mm
480x200mm
540x250
Max. movement of working table (LxW)
500x190mm
530x220mm
560x260
T-slot (No./width)
1x14mm
Max. distance from spindle center to table surface
335mm
440mm
420mm
Wheel size (Outer diameter x Width x Inner diameter)
180x13x31.75mm
200x20x31.75mm
Wheel speed
50Hz
2850r/min
60Hz
3440r/min
3360r/min
Vertical feed on handwheel
Per revolution
1.25mm
2.5mm
4.0mm
Per graduation
0.01mm
0.02mm
Cross feed on handwheel
Spindle motor
1.1kW
1.5kW
Coolant pump motor
40W
The parallelism of working surface to base level
300:0.005mm
Surface roughness
Ra0.32μm
N.W./G.W.
650/750kg
750/850kg
850/950kg
Packing size
100x115x176cm
114x125x194cm
120x140x194cm
Standard Accessories
Tool box
Balancing stand and bar
Flange wrench
Screw driver
Balancing screw
Open-end wrench
Inner hexagon spanner
Wheel dresser holder
Diamond pen
Machine stand pad
Grinding wheel and wheel flange
Magnetic chuck
