5kg and 1kg wire coil interchange.
3 in 1 function, including MIG/MAG, MMA, Lift TIG.
MMA mode with adjustable VRD control, user can set; arc force can adjust separately.
2T/4T mode.
At MIG/MAG mode have voltage, current, inductance unified adjusting function.
With output polarity conversion.
With perfect over current, overheating, short voltage protection.
Current and voltage figure have separate digital display.
Complete with spool gun connector.
|
Specifications |
MIG175GD |
|||||
|
Power supply voltage |
110/220V±15% |
|||||
|
Frequency |
50/60Hz |
|||||
|
Voltage |
110V |
220V |
||||
|
Mode |
MIG |
MMA |
TIG |
MIG |
MMA |
TIG |
|
Rated input power |
3kW |
3.7kW |
2.2kW |
5kW |
5.9kW |
3.7kW |
|
Rated input current |
37.3A |
46.3A |
21.6A |
31A |
37A |
23A |
|
Duty cycle (40°C 10min) |
30% 120A |
30% 175A |
||||
|
No load voltage |
62V |
|||||
|
Welding current range |
40-120A |
40-120A |
15-120A |
40-175A |
40-175A |
15-175A |
|
Welding voltage range |
15.5-22V |
|
|
15.5-24V |
|
|
|
Efficiency |
≥80% |
|||||
|
Power factor |
0.73 |
|||||
|
Protection class |
IP21 |
|||||
|
Insulation class |
F |
|||||
|
Cooling |
AF |
|||||
|
Wire diameter |
0.6/0.8mm |
1.6-3.2mm |
|
0.6/0.8/0.9mm |
1.6-4.0mm |
|
|
Net weight |
19.0kg |
|||||
|
Gross weight |
21.5kg |
|||||
|
Packing size |
575x285x575mm |
|||||
