Specifications |
MIG250GF |
MIG250GF3 |
MIG300GF |
|||
|
Power supply voltage |
220V±15% |
380V±15% |
||||
|
Frequency |
50/60Hz |
|||||
|
Mode |
MIG |
MMA |
MIG |
MMA |
MIG |
MMA |
|
Rated input power |
8.3kW |
9.4kW |
7.8kW |
8.8kW |
10.2kW |
11.3kW |
|
Rated input current |
51.6A |
58.4A |
13A |
15A |
16.7A |
18.5A |
|
Duty cycle (40°C 10min) |
60% 250A |
45% 250A |
40% 300A |
|||
|
No load voltage |
61V |
60V |
||||
|
Welding current range |
50-250A |
25-250A |
50-250A |
25-250A |
50-300A |
25-300A |
|
Welding voltage range |
14-28V |
|
14-28V |
|
15-32V |
|
|
Efficiency |
≥80% |
≥85% |
||||
|
Power factor |
0.73 |
0.93 |
||||
|
Protection class |
IP21 |
|||||
|
Insulation class |
F |
|||||
|
Cooling |
AF |
|||||
|
Wire diameter |
0.8/0.9/1.0mm |
1.6-5.0mm |
0.8/1.0/1.2mm |
1.6-5.0mm |
0.8/1.0/1.2mm |
1.6-5.0mm |
|
Net weight |
66.6kg |
66.6kg |
71.6kg |
|||
|
Gross weight |
81.6kg |
81.6kg |
86.6kg |
|||
|
Packing size |
1035x400x800mm |
|||||
