MIG/MMA Mode.
MMA mode with VRD control.
2T/4T Mode.
With output polarity conversion.
With perfect over current, overheating, under voltage protection.
Current and voltage figure with separate digital display.
3 duct design (waterproof, anti dust, anti corrosion).
The high rate of sustained load can be used for industrial users.
|
Specifications |
MIG350GF |
MIG400GF |
MIG500GF |
|||
|
Power supply voltage |
380V±15% |
|||||
|
Frequency |
50/60Hz |
|||||
|
Mode |
MIG |
MMA |
MIG |
MMA |
MIG |
MMA |
|
Rated input power |
13kW |
14kW |
16kW |
16.9kW |
22.9kW |
23.5kW |
|
Rated input current |
21.3A |
22.9A |
26.2A |
27.7A |
37.5A |
38.5A |
|
Duty cycle (40°C 10min) |
60% 350A |
40% 400A |
40% 500A |
|||
|
No load voltage |
65V |
75V |
||||
|
Welding current range |
50-350A |
30-350A |
50-400A |
40-400A |
50-500A |
25-500A |
|
Welding voltage range |
15-31.5V |
|
15-38V |
|
15-45V |
|
|
Efficiency |
≥85% |
|||||
|
Power factor |
0.93 |
|||||
|
Protection class |
IP21 |
|||||
|
Insulation class |
F |
|||||
|
Cooling |
AF |
|||||
|
Wire diameter |
0.8/1.0/1.2mm |
1.6-5.0mm |
0.8/1.0/1.2/1.6mm |
1.6-5.0mm |
0.8/1.0/1.2/1.6mm |
1.6-5.0mm |
|
Net weight |
72.9kg |
74.6kg |
75.8kg |
|||
|
Gross weight |
87.2kg |
89.6kg |
91.8kg |
|||
|
Packing size |
1035x400x800mm |
|||||
