Single phase power supply.
MMA/LIFT TIG Mode.
MMA mode with VRD control.
With perfect over current, overheating, short voltage protection.
Plastic cover, small size, light weight, portable and easy operation for family users.
Digital panel design, intuitive display, stable arc, suitable for DlY.
|
Specifications |
MMA120GDps |
|
|
Power supply voltage |
115V±15% |
200V±15% |
|
Frequency |
50/60Hz |
|
|
Rated input power |
3.7kW |
3.7kW |
|
Rated input current |
44.3A |
23.2A |
|
Duty cycle (40°C 10min) |
30% 120A |
30% 120A |
|
No load voltage |
65V |
|
|
Welding current range |
10-120A |
15-120A |
|
Efficiency |
≥80% |
|
|
Power factor |
0.73 |
|
|
Protection class |
IP21 |
|
|
Insulation class |
F |
|
|
Cooling |
AF |
|
|
Electrode diameter |
1.6~3.2mm |
|
|
Net weight |
3.5kg |
3.6kg |
|
Gross weight |
5.2kg |
5.3kg |
|
Packing size |
325x310x265mm |
325x310x265mm |
