Gears in headstock are made of top quality steel and hardened, ground.
Full featured carriage worktable with 2pcs of T-slots for setting accessories.
The rigid and stable column base is fixed to the worktable and adjusted for balance.
Spindle speed with digital readout and with feed digital depth ruler.
|
Specifications |
MP250C |
|
Swing over bed |
250mm |
|
Distance between centers |
700mm |
|
Bed width |
135mm |
|
Spindle bore |
27mm |
|
Spindle taper |
MT4 |
|
Spindle speed |
105-1600rpm |
|
Metric thread |
0.2-3.5 mm |
|
Inch thread |
56-8TPI |
|
Tailstock quill taper |
MT2 |
|
Tailstock quill travel |
60mm |
|
Main motor |
750W |
|
Drilling capacity |
16mm |
|
End milling capacity |
25mm |
|
Face milling capacity |
45mm |
|
Milling head spindle taper |
MT3 |
|
Milling head spindle travel |
180mm |
|
Milling head spindle speed |
50-2250rpm |
|
Distance from spindle nose to table surface |
280mm |
|
Milling head motor |
550W |
|
N.W. |
240/265kg |
|
Packing size |
1470x580x1020mm |
