Gears in headstock are made of top quality steel and hardened, ground.
Full featured carriage worktable with 2pcs of T-slots for setting accessories.
The rigid and stable column base is fixed to the worktable and adjusted for balance.
Powered lifting for mill/drill headstock and with feed digital depth ruler.
|
Specifications |
MP330G |
|
Swing over bed |
330mm |
|
Swing over cross slide |
185mm |
|
Distance between centers |
750/915mm |
|
Bed width |
160mm |
|
Top slide travel |
100mm |
|
Cross slide travel |
160mm |
|
Spindle bore |
38mm |
|
Spindle taper |
MT5 |
|
Spindle speed |
65-1800rpm |
|
Metric thread |
14 kinds 0.25-6mm |
|
Inch thread |
18 kinds 120-4TPI |
|
Tailstock quill taper |
MT3 |
|
Tailstock quill travel |
80mm |
|
Main motor |
900/1100W |
|
Drilling capacity |
16mm |
|
End milling capacity |
20mm |
|
Face milling capacity |
63mm |
|
Milling head spindle taper |
MT3 |
|
Milling head spindle travel |
180 |
|
Milling head spindle speed |
6 steps 190-2200rpm |
|
Distance from spindle nose to table surface |
315 |
|
Distance from spindle center to column surface |
210 |
|
T-slot width |
10mm |
|
Column diameter |
80mm |
|
Milling head tilt |
±90º |
|
Milling head rotation around column |
360º |
|
Milling head motor |
900/1100W |
|
N.W. |
470/520kg |
|
Machine size |
1460/1660x780x1150mm |
