With foot control.
It is easy for operation and relax hands for adjusting the material.
They have the function of air spring which can be installed inside the arm (optional).
The press blade and folding blade are segment structure.
Compression spring for top counterbalance.
Cam lock and rebound spring for bending beam counterbalance.
Bow handle for bending beam rotation.
Adjustable bending angle stop with scale up to 135°.
Segmented top beam tools.
|
Model |
PBB1020/2A |
PBB1270/2A |
PBB1520/1.5A |
|
Max. working length |
1020mm |
1270mm |
1520mm |
|
Max. sheet thickness |
2.0mm |
2.0mm |
1.5mm |
|
Max. clamping bar lift |
47mm |
47mm |
47mm |
|
Folding angle |
0-135° |
0-135° |
0-135° |
|
Packing size |
146x64x131cm |
171x71x131cm |
196x71x130cm |
|
N.W./G.W. |
325/390kg |
370/450kg |
395/466kg |
