Welded steel structure and vibratory stress relief, so the precision is well maintained.
Adopts three point rolling guide, disc spring to eliminate the gap between guides to improve the quality of cutting.
Rectangular blades, with four edges can be used to ensure a long service life.
The top blade carrier adopts inner slanting construction to ease unloading working piece to promote the quality of working pieces.
CNC system can automatically calculate and adjust the shearing angle, blade gap and stroke according the material texture, thickness and width. And it improves the precision and efficiency of cutting.
|
Model |
Shear |
Shear |
Stroke |
Back |
Shear |
Throat |
Motor |
Net |
Dimensions |
|
QC11K-4X2000 |
4mm |
2000mm |
16-25time/min |
20-600mm |
0.5°-2° |
100mm |
4kW |
3200kg |
2580x2020x1560mm |
|
QC11K-4X2500 |
4mm |
2500mm |
16-25time/min |
20-600mm |
0.5°-2° |
100mm |
5.5kW |
4000kg |
3100x2020x1600mm |
|
QC11K-4X3200 |
4mm |
3200mm |
16-25time/min |
20-600mm |
0.5°-2° |
100mm |
5.5kW |
5700kg |
3800x2020x1700mm |
|
QC11K-4X4000 |
4mm |
4000mm |
16-25time/min |
20-600mm |
0.5°-2° |
100mm |
7.5kW |
7200kg |
4700x2150x1920mm |
|
QC11K-6X2500 |
6mm |
2500mm |
10-25time/min |
20-600mm |
0.5°-2° |
100mm |
7.5kW |
5800kg |
3100x2200x1850mm |
|
QC11K-6X3200 |
6mm |
3200mm |
10-25time/min |
20-600mm |
0.5°-2° |
100mm |
7.5kW |
6500kg |
3800x2200x1865mm |
|
QC11K-6X4000 |
6mm |
4000mm |
10-25time/min |
20-600mm |
0.5°-2° |
100mm |
7.5kW |
8500kg |
4730x2200x2080mm |
|
QC11K-6X5000 |
6mm |
5000mm |
8-20time/min |
20-900mm |
0.5°-1.5° |
100mm |
7.5kW |
13000kg |
5730x2250x2210mm |
|
QC11K-6X6000 |
6mm |
6000mm |
8-20time/min |
20-900mm |
0.5°-1.5° |
100mm |
11kW |
16000kg |
6730x2250x2300mm |
|
QC11K-8X2500 |
8mm |
2500mm |
10-25time/min |
20-600mm |
0.5°-2° |
100mm |
11kW |
7000kg |
3100x2220x1850mm |
|
QC11K-8X3200 |
8mm |
3200mm |
10-25time/min |
20-600mm |
0.5°-2° |
100mm |
11kW |
8100kg |
3800x2220x2000mm |
|
QC11K-8X4000 |
8mm |
4000mm |
10-25time/min |
20-600mm |
0.5°-2° |
100mm |
11kW |
9200kg |
4600x2220x2100mm |
|
QC11K-10X2500 |
10mm |
2500mm |
10-25time/min |
20-600mm |
0.5°-2° |
100mm |
15kW |
8300kg |
3200x2220x1880mm |
|
QC11K-10X3200 |
10mm |
3200mm |
10-25time/min |
20-600mm |
0.5°-2° |
100mm |
15kW |
9250kg |
3800x2220x2000mm |
|
QC11K-10X4000 |
10mm |
4000mm |
10-25time/min |
20-600mm |
0.5°-2° |
100mm |
15kW |
10500kg |
4610x2300x2100mm |
|
QC11K-12X2500 |
12mm |
2500mm |
6-20time/min |
20-900mm |
0.5°-2.5° |
250mm |
18.5kW |
8600kg |
3110x2750x1950mm |
|
QC11K-12X3200 |
12mm |
3200mm |
6-20time/min |
20-900mm |
0.5°-2.5° |
250mm |
18.5kW |
11500kg |
3810x2750x2050mm |
|
QC11K-12X4000 |
12mm |
4000mm |
6-20time/min |
20-900mm |
0.5°-2.5° |
250mm |
18.5kW |
14200kg |
4610x2800x2150mm |
|
QC11K-16X2500 |
16mm |
2500mm |
5-15time/min |
20-900mm |
0.5°-2.5° |
250mm |
22kW |
12200kg |
3280x2800x2165mm |
|
QC11K-16X3200 |
16mm |
3200mm |
5-15time/min |
20-900mm |
0.5°-2.5° |
250mm |
22kW |
13700kg |
3880x2835x2265mm |
|
QC11K-16X4000 |
16mm |
4000mm |
5-15time/min |
20-900mm |
0.5°-2.5° |
250mm |
22kW |
16800kg |
4680x2835x2380mm |
|
QC11K-20X2500 |
20mm |
2500mm |
5-15time/min |
20-900mm |
0.5°-3° |
250mm |
30kW |
13000kg |
3200x2855x2200mm |
|
QC11K-20X3200 |
20mm |
3200mm |
5-15time/min |
20-900mm |
0.5°-3° |
250mm |
30kW |
16100kg |
3900x2855x2300mm |
|
QC11K-20X4000 |
20mm |
4000mm |
4-15time/min |
20-900mm |
0.5°-3° |
250mm |
37kW |
23000kg |
4760x2855x2420mm |
|
QC11K-25X2500 |
25mm |
2500mm |
4-15time/min |
20-900mm |
0.5°-3.5° |
250mm |
37kW |
22700kg |
3200x2900x2500mm |
|
QC11K-25X3200 |
25mm |
3200mm |
4-15time/min |
20-900mm |
0.5°-3.5° |
250mm |
37kW |
27200kg |
3900x2900x2700mm |
|
QC11K-25X4000 |
25mm |
4000mm |
4-15time/min |
20-900mm |
0.5°-3.5° |
250mm |
45kW |
31500kg |
4700x2900x2900mm |
