Order example
SK10-6 SK10-6AA SK10-6P
AA:PRECISION
P:ULTRA PRECISION
|
Model |
D |
d1 |
d2 |
L |
L1 |
L2 |
|
SK6 |
10.5 |
7.5 |
5.8 |
25 |
17 |
4 |
|
SK10 |
15.6 |
11.8 |
10 |
30 |
21.3 |
5 |
|
SK16 |
24.6 |
18.8 |
16 |
45 |
32 |
8 |
|
SK25 |
35.6 |
28.8 |
25.4 |
57 |
43 |
8.5 |
|
ModeL
|
Type
|
Range
|
|
Model
|
Type
|
Range
|
|
SK6
SK6-AA SK6-P |
SK6-2.0
|
2.0~1.75
|
SK16
SK16-AA SK16-P |
SK16-3.0
|
3.0~2.75
|
|
|
SK6-2.25
|
2.25~2.0
|
SK16-3.5
|
3.5~3.1
|
|||
|
SK6-2.5
|
2.5~2.25
|
SK16-4.0
|
4.0~3.6
|
|||
|
SK6-2.75
|
2.75~2.5
|
SK16-4.5
|
4.5~4.1
|
|||
|
SK6-3.0
|
3.0~2.75
|
SK16-5.0
|
5.0~4.6
|
|||
|
SK6-3.5
|
3.5~3.1
|
SK16-5.5
|
5.5~5.1
|
|||
|
SK6-4.0
|
4.0~3.6
|
SK16-6.0
|
6.0~5.6
|
|||
|
SK6-4.5
|
4.5~4.1
|
SK16-6.5
|
6.5~6.1
|
|||
|
SK6-5.0
|
5.0~4.6
|
SK16-7.0
|
7.0~6.6
|
|||
|
SK6-5.5
|
5.5~5.1
|
SK16-7.5
|
7.5~7.1
|
|||
|
SK6-6.0
|
6.0~5.6
|
SK16-8.0
|
8.0~7.6
|
|||
|
|
|
|
SK16-8.5
|
8.5~8.1
|
||
|
ModeL
|
Type
|
Range
|
SK16-9.0
|
9.0~8.6
|
||
|
SK10
SK10-AA SK10-P |
SK10-2.0
|
2.0~1.75
|
SK16-9.5
|
9.5~9.1
|
||
|
SK10-2.25
|
2.25~2.0
|
SK16-10.0
|
10.0~9.6
|
|||
|
SK10-2.5
|
2.5~2.25
|
SK16-10.5
|
10.5~10.1
|
|||
|
SK10-2.75
|
2.75~2.5
|
SK16-11.0
|
11.0~10.6
|
|||
|
SK10-3.0
|
3.0~2.75
|
SK16-11.5
|
11.5~11.1
|
|||
|
SK10-3.5
|
3.5~3.1
|
SK16-12.0
|
12.0~11.6
|
|||
|
SK10-4.0
|
4.0~3.6
|
SK16-12.5
|
12.5~12.1
|
|||
|
SK10-4.5
|
4.5~4.1
|
SK16-13.0
|
13.0~12.6
|
|||
|
SK10-5.0
|
5.0~4.6
|
SK16-13.5
|
13.5~13.1
|
|||
|
SK10-5.5
|
5.5~5.1
|
SK16-14.0
|
14.0~13.6
|
|||
|
SK10-6.0
|
6.0~5.6
|
SK16-14.5
|
14.5~14.1
|
|||
|
SK10-6.5
|
6.5~6.1
|
SK16-15.0
|
15.0~14.6
|
|||
|
SK10-7.0
|
7.0~6.6
|
SK16-15.5
|
15.5~15.1
|
|||
|
SK10-7.5
|
7.5~7.1
|
SK16-16.0
|
16.0~15.6
|
|||
|
SK10-8.0
|
8.0~7.6
|
|
||||
|
SK10-8.5
|
8.5~8.1
|
|||||
|
SK10-9.0
|
9.0~8.6
|
|||||
|
SK10-9.5
|
9.5~9.1
|
|||||
|
SK10-10.0
|
10.0~9.6
|
|||||
|
ModeL |
Type |
Range |
|
ModeL |
Type |
Range |
|
SK20 |
SK20-3.0 |
3.0~2.75 |
SK25 |
SK25-6.0 |
6.0~5.5 |
|
|
SK20-4.0 |
4.0~3.5 |
SK25-8.0 |
8.0~7.5 |
|||
|
SK20-5.0 |
5.0~4.5 |
SK25-10.0 |
10.0~9.5 |
|||
|
SK20-6.0 |
6.0~5.5 |
SK25-12.0 |
12.0~11.5 |
|||
|
SK20-8.0 |
8.0~7.5 |
SK25-16.0 |
16.0~15.5 |
|||
|
SK20-10.0 |
10.0~9.5 |
SK25-20.0 |
20.0~19.5 |
|||
|
SK20-12.0 |
12.0~11.5 |
SK25-25.0 |
25.0~24.5 |
|||
|
SK20-16.0 |
16.0~15.5 |
|
||||
|
SK20-20.0 |
20.0~19.5 |
|||||
