WC67E-30T/1600,WC67E-30T/2000,WC67E-40T/2500,WC67E-63T/2500,WC67E-63T/3200,WC67E-80T/2500,WC67E-80T/3200,WC67E-100T/2500,WC67E-100T/3200,WC67E-100T/4000,WX67Y-100T/4000,WC67E-125T/3200,WC67E-125T/4000,WX67Y-125T/4000,WC67E-160T/2500 Hydraulic Press Brake

Electro-hydro CNC Press Brake

CNC press brake has better bending accuracy and higher bending efficiency, and the bending times are increased by at least 30% in the same bending time.

Controller Brand: DELEM, CYBELEC, ESA

We use Cookie to improve your online experience. By continuing browsing this website, we assume you agree our use of Cookie.

Feature	FIG.
Outlook NC press brake machine not only meets the requirements of sheet metal bending, but also has better cost performance.
NC Controller Estun E300P series can control X and Y axis and the bending steps can be editted in the controller; In addition, Etune E300P, Delem DA41T and Cybelec CT8 controller have additional angle programming functions, touch screen and R-axis control functions, which make the bending easier.
Hydraulic System High quality hydraulic valve (Rexroth brand) is adopted, which is resistant to high pressure, durable and trouble free. It can realize the actions of ram rapid descent, slow descent, bending at working speed, rapid return and emergency stop of ram in the process of up and down. The machine can work continuously under the rated load, the hydraulic system has no leakage and is continuously stable with high precision.
Motor As a well-known brand in Germany, Siemens motor has the advantages of high efficiency, energy saving, large starting torque, good performance, low noise, low vibration, high reliability, power level and installation size in line with IEC standards and convenient use and maintenance. We can customize the power and voltage according to the customer's local voltage.
Oil Pump The oil pump adopts (USA Sunny) gear pump with low noise, made of high-strength cast iron, unique internal noise reduction design and can withstand high pressure. Low sensitivity to oil pollution to ensure long service life.
Backgauge Independently designed high-precision rear stop assembly, equipped with high-precision ball screw, adjustable stop finger and manual lifting, which can adapt to different punches.
Electrical Parts Adopts genuine Schneider pieces imported from France, which is stable and durable with long service life; Equipped with Estun original adaptive electrical box assembly, with strong anti-interference ability and stable electrical operation.
Crowning The mechanical compensation worktable can effectively eliminate the influence of ram deformation on bending accuracy by adjusting the bulge at each position in the middle (multi-point compensation worktable / manual deflection compensation worktable), and correct the angle error at different positions in the middle.
Punches & Dies Press brake punches and dies will be one of the most important topics we discuss before you place the order. Any bending shape will be completed by a suitable set of punch and die. We can provide appropriate tools according to different bending requirements of customers.
Torsion-sync Bar Torsion-sync principle controls the up and down movement of the ram.
Backgauge Servo Motor Servo motor control, with higher precision.
