Specifications |
X6132 |
X6132B |
X6132H |
X6132BH |
|
Table size |
320x1325mm |
320x1600mm |
320x1325mm |
320x1600mm |
|
Max. longitudinal travel (manual/auto) |
700/680mm |
900/880mm |
700/680mm |
900/880mm |
|
Max. cross travel (manual/auto) |
255/240mm |
|||
|
Max. vertical travel (manual/auto) |
320/300mm |
410/390mm |
||
|
Max. rotary angle of table |
±45° |
|||
|
Distance between spindle and table surface |
30/350mm |
30/440mm |
||
|
Spindle speed step |
18 steps |
|||
|
Spindle speed range |
30-1500rpm |
|||
|
Feed steps of table travel |
18 steps |
|||
|
Table feed range (X/Y/Z-axis) |
23.5-1180/23.5-1180/8-394mm/min |
|||
|
Main motor power |
7.5kW |
|||
|
Feed motor power |
1.5kW |
|||
|
Overall size |
2294x1770x1610mm |
2294x2050x1610mm |
2294x1770x1790mm |
2294x2050x1790mm |
|
N.W./G.W. |
2650/2950kg |
2740/3040kg |
2850/3150kg |
2940/3240kg |
|
|
|
|
|
|
|
Note: Ballscrews can be ordered instead of standard leadscrews as special request. |
||||
