Digital display showing clear RPM readings; speed is adjusted via a knob for convenient operation.
Upgraded performance, user-friendly operation and excellent value for money.
Features a variable-frequency drive for two-speed stepless speed control, with a wide range of spindle speeds suitable for machining various materials and components.
Centralised button layout for simple operation; the main gear is ground, whilst key components are machined using imported CNC technology, ensuring high precision and quiet operation for consistent machining quality.
The original pulley has been upgraded to provide six-speed stepless speed control, supporting high-torque drilling and high-speed small-hole drilling, eliminating the need to frequently open the pulley cover to adjust the speed.
|
Specifications |
Z3032X7VP |
|
Max. drilling capacity |
31.5mm |
|
Max. tapping capacity |
(Cast Iron) 22mm / (Steel) 16mm |
|
Distance from spindle center to column center |
300-700mm |
|
Column diameter |
150mm |
|
Spindle taper |
MT3 |
|
Spindle travel |
130mm |
|
Spindle speed |
75-438, 438-2500r/min |
|
Spindle speed step |
Variable |
|
Spindle feed |
0.08, 0.14, 0.23mm/r |
|
Rotation angle of the arm in horizontal plane |
360° |
|
Distance from spindle nose to base surface |
175-680mm |
|
Table size |
250x250x250mm |
|
Base size |
1220x640x150mm |
|
Main Motor |
1500W |
|
Overall size |
1235x640x1230mm |
|
N.W./G.W. |
500/540kg |
|
Packing size |
1330x750x1590mm |
|
Standard Accessories |
Optional Accessories |
|
Box shape worktable |
Stand |
|
Taper sleeve |
Angle vice |
|
Arbor |
Safety guard |
|
Drift |
|
|
Drill chuck |
