13mm (1/2'') max. chuck capacity.210mm swing.5 spindle speeds.-45° ~ 0° ~ +45° table tilt L&R.Optional chuck guard and micro switch for CE requirement.
Specifications
ZJ4113
Max. drilling diameter
13mm (1/2'')
Motor power
250/350W
Chuck capacity
1.5-13mm
Spindle travel
50mm
Class of speed
5
Speed 50/60Hz
620-2620/740-3140rpm
Spindle taper
B16
Max. distance from spindle axis to surface of column
105mm
Max. distance from spindle end to surface of table
220mm
Max. distance from spindle end to surface of base
300mm
Swing
210mm
Table size
160x160mm
Base size
290x190mm
Column diameter
46mm
Height
580mm
N.W./G.W.
16/17kg
Packing size
430x340x230mm
Standard Accessories
Optional Accessories
Key drill chuck
Keyless drill chuck
Side emergency switch
Safety chuck guard
Wrench set
Micro switch
Aluminium motor
Machine vice
Machine lamp
Cross laser light
Front emergency switch
Copper motor
