Construction by heavy solid cast iron.
Surface treated by multi-process spray treatment.
Variable speed with 2 steps, digital display in the panel.
With mandatory reversal function.
6 pole motor.
Better rigidity, good wearing quality, high precision, big power, excellent appearance.
Adopt to the transformation and upgrade of products in modern times.
Improve production efficiency.
|
Specifications |
ZS2032F-VS |
|
Max. drilling capacity |
32mm |
|
Max. tapping capacity |
M16 |
|
Chuck capacity |
B16 1~16mm |
|
Column diameter |
98mm |
|
Spindle travel |
135mm |
|
Swing |
510mm |
|
Max. distance spindle nose to table |
860mm |
|
Max. distance spindle nose to base |
1200mm |
|
Spindle taper |
MT3 |
|
Spindle speed range |
0~2100rpm |
|
Step of spindle speed |
Variable |
|
Table size |
410x380mm |
|
Base size |
650x440mm |
|
Overall height |
1770mm |
|
Motor power |
1100W |
|
Weight |
238kg |
|
Packing size |
1595x710x610mm |
